Sombrero Buoy 2028-Riser
The 2028 is the largest sombrero-style Jim Buoy in this line, featuring a 15 in riser mounted on a wide 30 in base and standing 50 in tall. It is designed to float with 35-40 lbs of chain and includes reinforced concrete internal ballast, a 5/8 in galvanized steel eye-bolt, and 200 stock labels.
Features
- High-density polyethylene shell
- 2-3 lb. density polyurethane internally foamed to waterline
- Reinforced concrete internal ballast
- 5/8 in galvanized steel eye-bolt
- Designed to float with 35-40 lbs of chain
- 200 stock labels included
- Orange, red, green, or silver reflective tape available
- Full foam fill available upon request
Specifications
| Specification | Detail |
|---|---|
| Riser Diameter | 15 in |
| Base Diameter | 30 in |
| Height | 50 in |
| Weight | 105 lbs |
| Material | High-density polyethylene shell with polyurethane foam |
| Color | White |
| Reflective Tape | Orange, red, green, or silver available |
Optional Additions
- Pick-up eye
- Radar reflectors
- Solar light (#9000)
- External ballast
- 2 in wide aluminum band
